Hardness:HRC56-60
Runout: 0.003 mm
Blancing: G2.5/25000 RPM
Usage: Working with induction shrink machine for mounting straight shank tools.
categories
Tool Holders
Bushing
Accessories
Non-Standard Tooling
HSK ● T
CAPTO
Module
TOOL HOLDER CLEANING DEVICE
-
Contact us
- Office Address: 253000, Chongde 5th Avenue, Gaotie New District, Dezhou, China
- Tel: +86-534-8127588
- Mob: +86-18865728871
- Email: sales@bright-tools.com
- Skype: sdjinjie101
Products
DIN69893 Shrink Chuck, 3°
contact now
| Product Origin: | China |
|---|---|
| Brand: | creater |
| Shipping Port: | Qingdao Shanghai |
| Payment: | T/T |
- Specification
- Simple figure
- Precautions
Material:Heat shrinkable steel
Hardness:HRC56-60 Runout: 0.003 mm Blancing: G2.5/25000 RPM Usage: Working with induction shrink machine for mounting straight shank tools.
|
|
| Size | d | D | L | L2 | L1 | N | G |
| HSK50A-SFS03-80 | 3 | 9 | 80 | 54 | - | - | - |
| HSK50A-SFS04-80 | 4 | 10 | 80 | 54 | - | - | - |
| HSK50A-SFS06-80 | 6 | 12 | 80 | 54 | 36 | 10 | M5 |
| HSK50A-SFS08-80 | 8 | 14 | 80 | 54 | 36 | 10 | M6 |
| HSK50A-SFS10-85 | 10 | 16 | 85 | 59 | 42 | 10 | M8x1 |
| HSK50A-SFS12-90 | 12 | 18 | 90 | 64 | 47 | 10 | M10x1 |
| HSK50A-SFS16-95 | 16 | 22 | 95 | 69 | 50 | 10 | M12x1 |
| HSK63A-SFS03-80 | 3 | 9 | 80 | 54 | - | - | - |
| HSK63A-SFS04-80 | 4 | 10 | 80 | 54 | - | - | - |
| HSK63A-SFS06-80 | 6 | 12 | 80 | 54 | 36 | 10 | M5 |
| HSK63A-SFS08-80 | 8 | 14 | 80 | 54 | 36 | 10 | M6 |
| HSK63A-SFS10-85 | 10 | 16 | 85 | 59 | 42 | 10 | M8x1 |
| HSK63A-SFS12-90 | 12 | 18 | 90 | 64 | 47 | 10 | M10x1 |
| HSK63A-SFS16-95 | 16 | 22 | 95 | 69 | 50 | 10 | M12x1 |
| HSK63A-SFS03-120 | 3 | 9 | 120 | 94 | - | - | - |
| HSK63A-SFS04-120 | 4 | 10 | 120 | 94 | - | - | - |
| HSK63A-SFS06-120 | 6 | 12 | 120 | 94 | 36 | 10 | M5 |
| HSK63A-SFS08-120 | 8 | 14 | 120 | 94 | 36 | 10 | M6 |
| HSK63A-SFS10-120 | 10 | 16 | 120 | 94 | 42 | 10 | M8x1 |
| HSK63A-SFS12-120 | 12 | 18 | 120 | 94 | 47 | 10 | M10x1 |
| HSK63A-SFS16-120 | 16 | 22 | 120 | 94 | 50 | 10 | M12x1 |
| HSK63A-SFS03-160 | 3 | 9 | 160 | 134 | - | - | - |
| HSK63A-SFS04-160 | 4 | 10 | 160 | 134 | - | - | - |
| HSK63A-SFS06-160 | 6 | 12 | 160 | 134 | 36 | 10 | M5 |
| HSK63A-SFS08-160 | 8 | 14 | 160 | 134 | 36 | 10 | M6 |
| HSK63A-SFS10-160 | 10 | 16 | 160 | 134 | 42 | 10 | M8x1 |
| HSK63A-SFS12-160 | 12 | 18 | 160 | 134 | 47 | 10 | M10x1 |
| HSK63A-SFS16-160 | 16 | 22 | 160 | 134 | 50 | 10 | M12x1 |
| HSK63A-SFS1/8-3.15" | 0.125" | 0.59" | 3.15" | 2.13" | - | - | - |
| HSK63A-SFS3/16-3.15" | 0.187" | 0.59" | 3.15" | 2.13" | - | - | - |
| HSK63A-SFS1/4-3.15" | 0.250" | 0.83" | 3.15" | 2.13" | 1.42" | 0.39" | M5 |
| HSK63A-SFS5/16-3.15" | 0.312" | 0.83" | 3.15" | 2.13" | 1.42" | 0.39" | M6 |
| HSK63A-SFS3/8-3.35" | 0.375" | 0.94" | 3.35" | 2.32" | 1.65" | 0.39" | M8x1 |
| HSK63A-SFS1/2-3.54" | 0.500" | 1.06" | 3.54" | 2.52" | 1.85" | 0.39" | M10x1 |
The heat-shrinkable system usually uses the heat-sensitive coil to heat the grip part of the handle in a short time, so that the inside diameter of the handle expands accordingly. At this point, the tool is immediately loaded into the handle, resulting in a high radial clamping force, the tool is firmly clamped.
